• 255 mm dia highly polished chromed lamination roller. 0
  • 3 kw electric / oil heating system with PID digital controlled upto 120 C for thermal lamination.
  • Automatic hydraulical pressure, 5~60 bar to high quality thermal lamination finishing and manual pressure for below 90 gsm paper for plain lamination.
  • Duplex unwind station laterally micro adjustable up to 100 mm.
  • Water base lamination coating station SS 304 gum tray with worm wheel, U/D system.
  • Heavy duty rewinding station with felt clutch mounted on ball bearing.
  • Aluminum feed table (special anodized finish) with feeding gauge.
  • Manual feeding with 8 nos. belt with advance belt adjustment system film sleeting device & perforation device on main unwind station.
  • Standard Size 24”, 32”, 36”, 42”, 48”.
  • AC Motor (Kirloskar make) with speed reduction gear box variable speed drive electric control panel with AC drive controller with exhaust fan.
  • Hydrualic power pack with regulator, pressure guage (Electrically operated.)
  • Stock range 70~450 gsm paper or board.
  • Line speed 0~50 mtrs/min for water based & 0~25 mtrs/min for thermal lamination.
  • Reel to reel attachment and length counter.
  • Online sheet separator unit for thermal lamination only, which is suitable for BOPP & PVC film.
