• 255 mm dia highly polished chromed lamination roller.
  • 3 kw electric / oil heating system with PID digital controlled upto 120 C.
  • Automatic hydraulically pressure 5~60 bar for High quality thermal lamination finishing and manual pressure for below 90 gsm paper.
  • Duplex unwind station laterally micro adjustable, up to 50 + 50 mm.
  • Water base lamination coating station SS 304 gum tray with worm wheel U/D System.
  • Heavy duty rewinding station with felt clutch mounted on ball bearing.
  • Aluminum feed table (Special Anodized Finish) with feeding gauge.
  • Manual feeding with 8 nos. belt with advance belt adjustment system.
  • Film sleeting device & perforation device on main unwind station.
  • AC Motor (Kirloskar make) with speed reduction gear box variable speed drive electric control panel with AC Drive controller & Exhaust fan.
  • Hydrualic power pack with regulator, pressure guage (Electrically operated.)
  • Stock Range 70~450 gsm paper & board, Max sheet size 820 x 1150 mm.
  • Line speed 0~50 mtrs/min for water based & 0 ~25 mtrs/min for thermal lamination.
  • Online drying unit, 3 IR lamp with thyristor controlled.
  • Unwind station with break.
  • Delivery table with automatic sheet stacker and updown.
  • Line speed 0 ~125 meters per minute.
  • Automatic sheet separator suitable for BOPP & PVC film only.
  • Sheet separator pressure unit adjustable type according the sheet length.
  • Automatic sheet separator suitable for overlap, underlap & touch to touch sheet feeding.
  • Stock range 80~450 gsm paper or board.
  • 2 set pneumatically individual pressure provided for accurate sheet separation.
  • 1 hp Air compressor for pneumatic system.
  • Digital sheet counter with photo electric sensor.
